KMSP-CKSPI 1.1测试

Description Features

Housing material:

6063 aviation aluminum

6063 aviation aluminum stretch stamping cover

Die-cast aluminum end-cap

High strength aluminum alloy brackets

Surface Finish:

Electrostatically applied polyester powder coat

Installation:

Non-adjustable bracket

Luminaires are not allowed to be installed in low-lying water

Cable:

SPI:150mm five-core 2*2.0+3*0.3mm² (power+ signal 100 Megabit network speed cable)

Features Benefits:

1.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving

2. Support data transmission protocol SPI

3. Multibit Processing technigue:Support CCT color temperature adjustment,white balance management, color gray level correction management function.

4. High-freguency frame and high rate 4K imaging: the frame change frequency is up to 120Hz, the transmission rate is up to20.83Mbps to perfectly achieve all kinds of video plavback requirements, the picture is clear and smooth, no delay.

Optical Data

Power 5W

80°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	83.9	20.9	9.3	5.2	3.3
	Halo diameter (m)	1.5	3.0	4.5	6.1	7.6

Power 14W

80°	Distance (m)	1	2	3	4	5
	Max lumination (lx)	242.2	60.5	26.9	15.1	9.6
	Halo diameter (m)	1.3	2.7	4.1	5.5	6.9

Model Information

Model	Length	Power(Pcs)	Voltage	Color Temperature	Beam Angles	Control	Chips Brand
KMSP-CKSPI 1.1-PZ-120C40	L2000mm	9W(120PCS)	DC48V	R+G+B	65° / 80° / 105°	SPI	CREE EPISTAR SANAN
KMSP-CKSPI 1.1-PZ-90C30	L1500mm	7W(90PCS)
KMSP-CKSPI 1.1-PZ-72C24	L1200mm	6W(72PCS)
KMSP-CKSPI 1.1-PZ-60C20	L1000mm	5W(60PCS)
KMSP-CKSPI 1.1-PZ-30C10	L500mm	2W(30PCS)
KMSP-CKSPI 1.1-PZ-240C40	L2000mm	18W(240PCS)
KMSP-CKSPI 1.1-PZ-180C30	L1500mm	14W(180PCS)
KMSP-CKSPI 1.1-PZ-144C24	L1200mm	11W(144PCS)
KMSP-CKSPI 1.1-PZ-120C20	L1000mm	9W(120PCS)
KMSP-CKSPI 1.1-PZ-60C10	L500mm	5W(60PCS)
